Flooring
Internal
Flat Flooring: 800 x 800 mm Double Charged Vitrified, Designer tiles with Spacer Joint.
Master Bathroom Flooring: 600 x 1,200 mm Anti-Skid, Matte Finish, Designer Tiles with Spacer Joint.
Other Bathroom Flooring: 600 x 600 mm Anti-Skid, Matte Finish, Designer Tiles with Spacer Joint.
Balcony Flooring: Wood finish Anti-Skid Vitrified tiles with Spacer Joint.
Utility Flooring: 600 x 600 mm Porcelain/Ceramic Anti-Skid, Matte Finish tiles.
External
Corridor: 600 x 1,200 mm Vitrified GVT/Terrazzo Designer Tiling.
Joinery Works
Main Doors
Size: 2400 mm high & 1100 mm wide.
Frame: Teak wood frame finished with melamine spray polish.
Shutters: Oak Veneer shutters with designer hardware.
Bedroom Doors
Size: 2250 mm high & 950 mm wide.
Frame: Hardwood door frames.
Shutters: Two sides laminated shutters with designer hardware.
Bathroom Doors
Size: 2250 mm high & 800 mm wide.
Frame: Granite frame.
Shutters: Two sides laminated shutters with designer hardware.
Balcony
Size: 2250 mm high & 2100 mm wide, UPVC slide doors with provision for mosquito mesh.
Shutter: Toughened clear glass.
Windows
Frame: UPVC sliding/openable window system.
Shutters: Toughened clear glass with provision for mosquito mesh.
Bathroom Ventilators
Frame: UPVC frosted with openable shutters.
Shutters: Toughened clear glass.
Plumbing
Chrome Plated Fittings
Fixtures shall be from Grohe or equivalent provided for:
Bathroom Shower with diverter.
Basin Mixer for hot & cold water.
Bathroom Faucets.
Utility Trap.
Flush valve from Sloan or equivalent.
Sanitary
Fixtures shall be from Duravit or equivalent provided for:
Washbasin.
Wall-mounted EWC.
Electrical
Make
Wiring: Concealed PVC insulated copper wiring of reputed make.
Switch Boards: Modular switches from Legrand or equivalent.
Distribution Board: One distribution board for each flat from Schneider or Legrand or equivalent.
Location-wise power outlets
Bedrooms & Living Area: Power outlets for light, fan, Air-conditioners, TV, and charging points.
Bathrooms: Power outlets for light, geyser, and vanity.
Main Balcony: Power outlets for light, fan, and charging point.
Kitchen: Power outlets for Light, Chimney, Hob, Refrigerator, Microwave/Oven, Mixer/Grinder, Water Purifier, Dishwasher.
Utility Room: Power outlets for light, washing machine, and dryer.
Attached Balcony: Power outlets for light and charging point.
Hand Railing
Glass railing as per the design intent.
Parking
Markings
Designated markings for each flat and visitor parking. Signages at relevant points.
Car Wash Area
Will be provided in the basement.
EV Charging Point
Charging stations will be provided at dedicated spaces in the basement.
Lifts
High-speed lifts from Kone or equivalent make.
Passenger Lifts: 10 per tower.
Service Lifts: 02 per tower.
LPG
Piped LPG gas connection will be supplied from centralized gas bank to all flats.
Billing
Internal
Water, Gas, and Electricity Meters will be provided for each flat.
External
Application-based system will be provided for monitoring the domestic energy consumption and billing purposes.
Water Inlet
Kitchen/Utility
Washing Machine: One inlet point for washing machine.
Water Purifier: One inlet point for water purifier.
Sink: One inlet point for sink.
Internet / Cable / Telecom
Optic fibre cable for internet in the Living Area.
TV and DTH points in all bedrooms and Living area.
Intercom point in the Living area.
Power Backup
DG set with acoustic enclosure and AMFs.
Security/ BMS
CCTV cameras at designated locations and dedicated surveillance room to be provided.
Walls
Thickness
Flat walls: 100 or 200 mm thick RCC walls.
External walls: 200 or 230 mm thick RCC walls.
Paint
Flat walls: Smooth putty finish with two coats of cement/acrylic emulsion paint from Asian Paints or equivalent.
External walls: Texture finish and two coats of exterior emulsion paint from Asian Paints or equivalent.
Cladding
Master Bathroom Wall: 600 x 1,200 mm GVT/Porcelain tiles cladding up to false ceiling height.
Other Bathroom Walls: 600 x 600 mm GVT/Porcelain tiles cladding up to false ceiling height.
Utility Walls: Porcelain/Ceramic tiles cladding up to 3 feet height.
Tower Entrance Lobby: Designer tiles cladding for double-heighted lobby of around 15 feet.
Ground Floor Lift Lobby: Granite/Marble cladding for double-height lobby of around 15 feet.
Typical & Basement Lift Lobby: Designer tiles/Granite cladding.
Ceiling
Flat Ceiling: Smooth putty finish with acrylic emulsion paint.
Bathroom Ceiling: Grid false ceiling to cover all service lines.
Utility Room Ceiling: Grid false ceiling to cover all service lines.
Balcony Ceiling: Smooth putty finish with acrylic emulsion paint.
Foundation & Structural Frame
RCC Shear Wall structure to withstand wind and seismic loads (Zone 2).
Fire Safety
Fire equipment as per NBC regulations.
Fire alarms, fire hydrants, fire sprinkler system, and fire curtains will be provided as per fire norms.
Solar Power
Solar system will be provided on terrace with rating as per the norms.
Water Supply / Treatment
Water treatment plant (WTP) for softening and treating water (Not RO).
Sewage treatment plant (STP) of adequate capacity as per regulatory norms.
Treated sewage will be used for flushing and landscaping purposes.
Rainwater harvesting pits provided for recharging groundwater level (as per norms).
Common Area
Power for common area lighting will be provided from Solar, transformer, and DG.
Misc
Mechanical Ventilation
Mechanical ventilation system will be provided in the basements as per NBC norms.
Garbage Chute
2 sets of garbage chutes will be provided on every floor of each tower, of reputed make.
